Next-Generation Firewall
FortiGate 101F
Orta ölçekli işletmeler için yüksek performanslı güvenlik duvarı. Gelişmiş güvenlik ve yüksek kullanılabilirlik.
Özellikler
- 20 Gbps Firewall Throughput
- 2.6 Gbps IPS Throughput
- SSL Inspection
- SD-WAN
- HA Support
- Multi-WAN
Kimler için
Orta ölçekli işletmeler; yüksek kullanılabilirlik (HA) ve birden fazla WAN hattı gereken ağlar.
Teknik özellikler
| GE RJ45 Port | 12 |
|---|---|
| GE RJ45 Management Ports | 1 |
| High Availability Port | 2 |
| DMZ Ports | 1 |
| GE SFP Port | 4 |
| 10GE SFP+ Ports | 2 |
| GE RJ45 WAN Port | 2 |
| GE RJ45 or SFP Shared Ports | 4 |
| USB Ports | 1 |
| Internal Storage | 1x 480 GB SSD |
| Included Transceivers | 0 |
| IPS Throughput | 2.6 Gbps |
| NGFW Throughput | 1.6 Gbps |
| Threat Protection Throughput | 1 Gbps |
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 20/18/10 Gbps |
| Firewall Latency (64 byte UDP packets) | 5 μs |
| Firewall Throughput (Packets Per Second) | 15 Mpps |
| Concurrent Sessions (TCP) | 1.5 Million |
| New Sessions/Second (TCP) | 56,000 |
| Firewall Policies | 10,000 |
| IPsec VPN Throughput (512 byte) | 11.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,500 |
| Client-to-Gateway IPsec VPN Tunnels | 16,000 |
| SSL-VPN Throughput | 750 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 500 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 1 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 1,800 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 135,000 |
| Application Control Throughput (HTTP 64K) | 2.2 Gbps |
| CAPWAP Throughput (1444 byte, UDP) | 15 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 24 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 64 / 32 |
| Maximum Number of FortiTokens | 5,000 |
| Maximum Number of Registered FortiClients | 600 |
| High Availability Configurations | Active / Active , Active / Passive , Clustering |
| Height x Width x Length (inches) | 1.73 x 17 x 10 |
| Height x Width x Length (mm) | 44 x 432 x 254 |
| Form Factor | 1 RU , Rack Mount |
| Weight | 7.56 lbs (3.43 kg) |
| Power Required | 100–240V AC, 50/60 Hz , 100–240V AC, 60/50 Hz |
| Maximum Current | 100Vac/1.0A , 240Vac/0.6A |
| Power Consumption (Average / Maximum) | 35.3 W / 39.1 W |
| Heat Dissipation | 121.13 BTU/h |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Humidity | 10–90% non-condensing |
| Noise Level | 40.4 dBA |
| Compliance | BSMI , CB , CE , Class A , FCC Part 15B , RCM , UL/cUL , VCCI |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6 |
| 10GE SFP+ FortiLink Ports | 2 |
| Redundant Power Supplies | Dual |
FortiGate ailesindeki yeri
Ürün kartlarındaki firewall ve IPS değerleri, küçükten büyüğe. Nihai seçim açık servislere ve trafiğe göre yapılır.
| Model | Firewall | IPS |
|---|---|---|
| FortiGate 40F | 5 Gbps | 1 Gbps |
| FortiGate 60F | 10 Gbps | 1.4 Gbps |
| FortiGate 61F | 10 Gbps | 1.4 Gbps |
| FortiGate 100F | 20 Gbps | 2.6 Gbps |
| FortiGate 101FBu ürün | 20 Gbps | 2.6 Gbps |
| FortiGate 200F | 27 Gbps | 5 Gbps |
